Mi-Light LED CCT RF 12 / 24V controller + remote control FUT040
15 verkauft in den letzten 24 Stunden
Switching on and dimming of two-color CCT strips
Artikelnummer |
180971 |
EAN |
6970602180971 |
MPN |
FUT040 |
Beschreibung
The controller allows you to smoothly adjust the brightness of the light and the color temperature of white light.
The device can work in the range of 12-24V DC and the maximum power cannot exceed 6A per channel and 12A of total power.
The front part consists of a combination of physical rubber buttons and touchpads.
The remote control with the receiver are paired and ready to go.
Spezifikationen
| Input Voltage | DC12V~24V |
| Output | 12A/Channel |
| Total Output | Max 12A |
| RF | 433MHz |
| Control Distance | 30m |
| Output Connection | Common anode |
| Working Temp. | -20~60°C |
| Working Voltage | 3V(2*AAA Battery) |
| Standby Power | 20uA |
| RF | 433MHz |
| Transmitting Power | <10mW |
| Modulation Method | ASK |
| Control Distance | 30m |
| Working Temp. | -20~60°C |
